UITableViewCellの利用
UITableViewでカスタムセルをコードで作成する方法です。UITableVIewの利用で作成したコードとの差分のみ掲載しています。完全なサンプルはこちらからどうぞ。
MyTableCell.h
まずはUITableViewCellを継承したMyTableCellを追加します。
#import <UIKit/UIKit.h> // Identifier extern NSString *myCellID; @interface MyTableCell : UITableViewCell { UILabel *titleLabel; } @property (nonatomic, retain) UILabel *titleLabel; @end
externで定義しているものが、Cell再利用用のIdentifierになります。
あとはCell内に表示するラベルを追加しています。
MyTableCell.m
Cellの実装部です。
#import "MyTableCell.h" NSString *myCellID = @"myCellID"; @implementation MyTableCell @synthesize titleLabel; - (id)initWithFrame:(CGRect)frame reuseIdentifier:(NSString *)reuseIdentifier { if (self = [super initWithFrame:frame reuseIdentifier:reuseIdentifier]) { // ラベルの設定 titleLabel = [[UILabel alloc] initWithFrame:frame]; titleLabel.font = [UIFont systemFontOfSize:15]; titleLabel.frame = CGRectMake(10.0, 0.0, 320.0, 40.0); [self.contentView addSubview:titleLabel]; // アクセサリーの設定 self.accessoryType = UITableViewCellAccessoryDetailDisclosureButton; } return self; } - (void)setSelected:(BOOL)selected animated:(BOOL)animated { [super setSelected:selected animated:animated]; } - (void)dealloc { [titleLabel release]; [super dealloc]; } @end
実装部では初期化時に画面に表示するラベルの設定と、セルの右側に表示されるアクセサリーの設定を行っています。contentViewにUI部品を追加すればセルに表示されます。
アクセサリーはこのほかにUITableViewCellAccessoryCheckmarkとUITableViewCellAccessoryDisclosureIndicatorの指定が可能です。
MyViewController.m
最後にCell生成ロジックの変更をします。
#import "MyTableCell.h" - (UITableViewCell *)tableView:(UITableView *)tableView cellForRowAtIndexPath:(NSIndexPath *)indexPath { MyTableCell *cell = (MyTableCell *)[myTableView dequeueReusableCellWithIdentifier: myCellID]; if (cell == nil) { cell = [[[MyTableCell alloc] initWithFrame:CGRectZero reuseIdentifier:myCellID] autorelease]; //ストライプ用の設定 UIView *bgView = [[UILabel alloc] initWithFrame:CGRectZero]; cell.backgroundView = bgView; [bgView release]; for(UIView *view in cell.contentView.subviews){ view.backgroundColor = [UIColor clearColor]; } } cell.titleLabel.text = [NSString stringWithFormat:@"%@ %i", @"row", indexPath.row]; //ストライプ用の設定 if(indexPath.row % 2){ cell.backgroundView.backgroundColor = [UIColor whiteColor]; }else{ cell.backgroundView.backgroundColor = [UIColor colorWithRed:0.0 green:0.0 blue:1.0 alpha:0.1]; } return cell; }
この部分はInterface Builderを使ってカスタムセルを作成する場合と変わりません。Identifierで定義されたCellが生成されていない場合のみ生成されます。ストライプの設定はUITableViewで縞模様(ストライプ)を参考にさせて頂きました。
